WS50 Skid Steer Loader (MDC type)
General specifications of WS50 skid steer loader | |
Engine | PERKINS 404 D-22 |
Rated power(kw) | 35.7/36.5 |
Rated speed(rpm) | 2600/2600 |
External dimensions: length * width * high | 3413*1780*2007(mm) |
Operating weight(kg) | 3003 |
Max travelspeed(km/h) | 12 |
Performance | |
Rated operating capacity(kg) | 750 |
Tipping load(kg) | 1500 |
Max.dump height(mm) | 2303 |
Max.dump distance(mm) | 675 |
Turn radlus,front tyre(mm) | 1230 |
Wheel base(mm) | 999 |
Bucke capacity(m3) | 0.35 |
Fuel tank capacity(m3) | 88 |
Hydraulic tank capacity(m3) | 70 |
Color | Machine body | Yellow |
| Engine | Perkins 404D-22 |
Working arm | Yellow | Hopper | Automatic balancing | ||
Back hood | Yellow | Control | Mechanical type | ||
Cabinet | Black | Quick change bracket | Universal | ||
Attachment | Black | Brake | Built out type | ||
Cabinet | Open type | Seat | Safety belt&bumper | ||
Tyre | 10-16.5 | ||||
Rain wiper | No | ||||
Attachment | Standard bucket | ||||
Lamp | Working lamp | Yes | Horn | Yes | |
Reverse Buzzer | Yes | Accelerator | Hand&feet controlled | ||
Indoor lamp | Yes | Rear mirror | Yes | ||
Hydraulic accessory | G1/2 pipe joint | ||||
Hydraulic system | Piston pump | Sauer Danfoss 44cc | Machine body | WS50 | |
High torque motor | Sauer Danfoss 398cc | Oil pipe | 24° | ||
Gear pump | Permco 25cc |
|
| ||
Leveling valve | Sauer Danfoss | ||||
Balance valve | Hydrocontrol | ||||
Hydraulic lock | Rexroth | ||||
Multi-way valve | Hydrocontrol | ||||
Magnetic valve | Sauer Danfoss | ||||
